CLAMPING UNIT

TECHNICAL CHARACTERISTICS

· Being optimized by finite element analysis,the even stress distribution on the platen minimizes the chance of deformation while can prolong its life time also.

· Parameters optimization design of connecting rod structure, guarantee run fast and smooth, small hedge-click

· Oversized ties bar margins, may mold thickness and mould opening stroke can carrying larger molds

· Use quantitative distribution of lubrication systems, lubrication of high pressure, high reliability

· Hydraulic motor drive gear adjusting, mould adjusting quickly and accurately.

· Low pressure mold protection function. Multiple ejector mode optional. High precision control of clamping and ejector position

STANDARD FEATURES

· Integral casting high intensity platen and toggle

· Mechanical and electric dual protection device

· Mold cooling water dispenser

· Floor place reserved for robot installation

· Code template hole template

OPTIONAL FEATURES

· Increase mold thickness

· Hydraulic core pul

· Rotate drawing

· Air ejector

· Hydraulic or electric daylight adjustment

· Mold Opening mechanical limit stop

· Mold hang up device

· Widening of safety door

· Automatic safety door

· T-slot mold platen
